Solar Panels/ PV Panels

400W Bifacial Monocrystalline PERC Solar Panels

400W Bifacial Monocrystalline PERC Solar Panels

Power: 400W Mono Bifacial Panel
Solar Cells: 108 Cell (6×18) — 10BB
Module Dimension: 1722×1134×30
Open-Circuit Voltage(Voc): 37.94V
Product description: 400W Monocrystalline Bifacial PERC Solar Panels half cell Residential Energy Storage System
INQUIRY

400W Monocrystalline Bifacial PERC 108Cells Residential Energy Storage System Solar Panels

400W Bifacial Glass Solar Panels Description:

1. The appearance of components are elegant and simple, perfectly combined with the architectural style.
2. 10BB is combined with 182*91mm cell technology, which has more reliable performance, effectively reduces the power loss caused and achieves higher power output.

3. Double-sided absorption of solar radiation, the double-sided ratio is as high as 70%, which greatly improves the equivalent power of the module

Solar Panel Application:

Highly used in Gound power plants, Commercial / Industrial roof-tops, Residential roof-tops, Agricultral PV Project

400W Bifacial Glass Panels Pamameters:

ELECTRICAL SPECIFICATION (STC)
Max-power	400
Power Tolerance	0~+6W
Voltage at Pmax (Vmp)	30.8
Current at Pmax (Imp)	12.99
Open-Circuit Voltage(Voc)	37.94
Short-Circuit Current (lsc)	13.8
Module Efficiency(%)	20.48
No. of Bypass Diodes(pcs.)	3
Max. Series Fuse(A)	25A
Operating Temperature	- 45~+85 ℃
Max Static Load	5400P
Max-System Voltage(VDC)	1500 VDC(IEC)
Fire Rating	Class C
STC: Irradiancec 1000W/m2, Cell Temperature 25 ℃,Air Mass 1.5
